| MF 260 PERFORMANCE: |
|
Engine HP @ 2250 RPM
Max. Torque @ 1600 RPM
Max. P.T.O Power @ rated Engine Speed
*Certified to BS AU 141a
* * Manufacturer's Estimate |
60 (BS)*
212 Nm
48 hp** |
| |
|
| MF 260 ENGINE: |
|
Make/Type
No. of Cylinders
Injection
Bore
Stroke
Capacity
Aspiration
Compression Ratio
Starting Aid
Throttle Control
Cooling
Air Cleaner Type
Air pre-cleaner
Fuel Filter
Exhaust
Oil Cooler |
Perkins/T3.1524
3
Direct Injection
91.4 mm
127 mm (5.0 in)
2.5 Liter (152.7 Cu. Ins.) Turbo
16.5:1
Thermostat
Hand and Foot
Water
Oil Bath
Over-bonnet air swirl
Dual High Capacity
Vertical
Air coated, Fin Type |
| |
|
| MF 260 ELECTRICS: |
|
Voltage
Battery
Starter
Alternator |
12 V, Negative Earth
96 Amp. Hour
2.2 kW
32 Amp |
| |
|
MF 260 CLUTCH:
Type
Diameter |
Dual
305 x 254 mm (12 x 10 in)
|
| |
|
| MF 260 TRANSMISSION: |
|
Type
Number of Gears
Road Speed at 2250 engine rpm with 14-/13-28 rear tyres
Gear
Forward 1
Forward 2
Forward 3
Forward 4
Forward 5
Forward 6
Forward 7
Forward 8
Reverse 1
Reverse 2 |
Sliding spur
8 Forward, 2 Reverse
Speed (kph)
2.7
3.9
5.3
7.2
10.6
15.6
21.3
28.7
3.6
14.5 |
| |
|
MF 260 POWER TAKE - OFF:
Type
Engine Speed @ 540 PTO rpm
Shaft Diameter
No. of Splines |
Live
1789 rpm
35 mm (1.375 in)
6
|
| |
|
MF 260 HYDRAULICS:
Functions
Pump Type
Maximum Oil Flow
Maximum Pressure
Max. lift capacity with lower links Horizontal lower links |
Draft Control
Position Control
Response Control
Constant Pumping
Reciprocating Ferguson Pump
16 liters/min. (3.52 lmp.gal/min)
19.2 Mpa (192.5 bars) at normal operating temperature
1415 Kg (3120 lbs.)
Category 1 & 2 Interchangeable Balls |
|
MF 260 FRONT AXLE:
Type |
Box Section, Adjustable |
| |
|
MF 260 STEERING:
Type |
Manual |
| |
|
| MF 260 REAR AXLE AND BRAKES: |
Axle Type
Brake Type
Brakes Actuation
Parking Brake |
Straddle with epicyclic reduction
Oil immersed, multi-disc
Mechanical
Hand Lever Operated |
| |
|
| MF 260 INSTRUMENTATION: |
Gauges
Warning Lights
|
Tachometer, Hour meter, Fuel Level, Battery condition & water temperature
Direction Indicators, Electric Charge, Head Light main beam, Low engine, Oil Pressure, Brake Lights |
| |
|
| MF 260 TYRES: |
|
Front
Rear |
7.50 - 16 (6PR) Pressed Wheels
14.9/13 - 28 (6PR) Pressed Wheels |
| |
|
| MF 260 TRACK ADJUSTMENT: |
Front
Rear |
1346-1854 mm
1423-2134 mm |
| |
|
| MF 260 WEIGHT AND DIMENSIONS: |
Weight:
Gross Weight
Dimension:
Wheel Base
Overall Length
Overall Width Minimum
Height:
- Over Exhaust
- Over Steering Wheel
Turning Circle:
- With Brakes
- With out Brakes
Ground Clearance: |
1890 kg
1892 mm
3260 mm
1753 mm
2145 mm
1410 mm
5970 mm
6700 mm
338 mm |
| |
|
| MF 260 CAPACITIES: |
|
Fuel Tank
Engine Sump
Cooling System
Hydraulic System
Steering Box
Oil bath air cleaner |
47.5 liters
6.8 liters
10.2 liters
33.0 liters
0.9 liters
0.5 liters |
| |
|
|
|
